VHS50
Thickness：0.8-3.5mm

Inquire Now

Model	VHS50-400-15A	VHS50-600-15A	VHS50-800-15A	VHS50-1000-15A	VHS50-1300-15A
Width	0-400mm	0-600mm	0-800mm	0-1000mm	0-1300mm
Roll diameter	50	50	50	50	50
Rated thickness	0.8-3.5mm	0.8-3.5mm	0.8-3.5mm	0.8-3.5mm	0.8-3.5mm
Maximum thickness	6.0mm	6.0mm	6.0mm	6.0mm	6.0mm
Number of rolls	15	15	15	15	15
Shortest part	90	90	90	90	90
Leveling speed	0-12m/min	0-12m/min	0-12m/min	0-12m/min	0-12m/min
Voltage	AC three-phase 380V AC3-phase 380V	AC three-phase 380V AC3-phase 380V	AC three-phase 380V AC3-phase 380V	AC three-phase 380V AC3-phase 380V	AC three-phase 380V AC3-phase 380V
Optional	1.Loading and unloading and reclaiming manipulators2. Loading and unloading joint robots 3.Automatic detection platform 4. inlet and outflow assembly line 5. Automatic stacking lifting platform 6. Roller quick cleaning device

VHS50Thickness：0.8-3.5mm
