| Model | VHS42-400-19A | VHS42-600-19A | VHS42-800-19A | VHS42-1000-19A | VHS42-1300-19A | VHS42-1600-19A |
| Width | 0-400mm | 0-600mm | 0-800mm | 0-1000mm | 0-1300mm | 0-1600mm |
Roll diameter | 42 | 42 | 42 | 42 | 42 | 42 |
| Rated thickness | 0.4-3.0mm | 0.4-3.0mm | 0.4-3.0mm | 0.4-3.0mm | 0.4-3.0mm | 0.4-3.0mm |
Maximum thickness | 5.0mm | 5.0mm | 5.0mm | 5.0mm | 5.0mm | 5.0mm |
| Number of rolls | 19 | 19 | 19 | 19 | 19 | 19 |
| Shortest part | 70 | 70 | 70 | 70 | 70 | 70 |
| Leveling speed | 0-12m/min | 0-12m/min | 0-12m/min | 0-12m/min | 0-12m/min | 0-12m/min |
| Voltage | AC three-phase380V AC3-phase 380V | AC three-phase380V AC3-phase 380V | AC three-phase380V AC3-phase 380V | AC three-phase380V AC3-phase 380V | AC three-phase380V AC3-phase 380V | AC three-phase380V AC3-phase 380V |
| Optional | 1.Loading and unloading and reclaiming manipulators2. Loading and unloading joint robots 3.Automatic detection platform 4. inlet and outflow assembly line 5. Automatic stacking lifting platform 6. Roller quick cleaning device | |||||
