Specifically designed for 0.8-4.0mm thick metal sheets, this series is widely used in industries such as construction, automotive, and heavy machinery manufacturing.
The production line integrates multiple functions including decoiling, leveling, and stamping, enabling efficient and precise processing of medium/heavy-gauge sheets while ensuring stable and reliable production.
Featuring innovative high-speed stamping technology and a precision leveling system, the equipment maintains high accuracy even at maximum operating speeds. The intelligent control system optimizes each processing stage to guarantee consistent batch-to-batch quality.
| Series | Material thickness | Width range | Stamping Speed | flatten | Coil Weight | Feeding Accuracy | |
| Ultra-Thin Sheet | UC | 0.1-0.8mm | 400/600/800/1000/1300 | 0-60m/min | 0.1-0.5/0.5-1.0/1.0mm | 0.5-5T | ±0.3-1.0mm/m |
| Thin-gauge sheet | TC | 0.4-1.5mm | 600/800/1000/1300/1600/2100/2600 | 0-40m/min | 0.1-0.5/0.5-1.0/1.0mm | 5T-10T | ±0.3-1.0mm/m |
| Medium-sheet | MC | 0.8-4.0mm | 600/800/1000/1300/1600/2100/2600 | 0-20m/min | 0.1-0.5/0.5-1.0/1.0mm | 10T-20T | ±0.3-1.0mm/m |
| Thick plate | HC | 3.0-16.0mm | 600/800/1000/1300/1600/2100/2600 | 0-10m/min | 0.1-0.5/0.5-1.0/1.0mm | 10T-30T | ±0.3-1.0mm/m |
| Extra-thick plate | XC | 6.0-25mm | 600/800/1000/1300/1600/2100/2600 | 0-10m/min | 0.1-0.5/0.5-1.0/1.0mm | 10T-30T | ±0.3-1.0mm/m |
We provide not only equipment but also professional services throughout the entire lifecycle:
